Hand-Held Fiber Laser Welding Machine STW1500E

Equipment Advantages:

  • Convenient and flexible for welding the large workpiece, such as sinks ans stainless steel kitchen cabinets,no need to move them to the workbench.

  • The heat affected area is small during welding, and it will not cause deformation, blackening, and traces on the back of the workpiece or depression in the joints. The connection depth is large, the welding is firm and the melting is sufficient.

  • High efficiency and greatly increased productivity. The welding speed is fast, 3-10 times faster than the traditional welding.

  • Simple operation,easy to learn,saving your expensive technical labor costs!

welding machine.jpg

Machine Features:

  • High-performance laser: Raycus/JPT/MAX laser source available, Fast and efficient, Long life and stable(100000 hours).

  • Built-in water cooler: Dustproof, fast cooling, Make sure the equipment is running at a constant temperature.

  • Hand-held gunThe overall lightness and flexibility, integrated gas automatic wire protection system feeding, and long service life.


Technical Parameters:


  Equipment NameHand-held Fiber Laser Welding Machine -STW1500E
Fiber laser Brand MAX/RAYCUS/JPT/BWT
  Laser Power
Controller&welding gunRD Cam/Super weiye/Qilin
  Laser Wavelength1070NM
  Fiber LengthStandard 8-10M, Suppurts up to 15M
  Wave of working Continuous  / Modulation
  Speed range 0-120mm/s
  Cooling water machine industrial constant tempreture water tank
  Working environment Tempreture 15℃-35℃, Humidity <70% without condensation
  Recommend welding thickness0.5-5mm
Operating voltage  AV220V 50HZ/60Hz; 380V/3PH/50HZ

 Machine details:

Fiber laser source

Choose different power according to the thickness of the plate(Option: 1500W/2000W/3000W)

  • Excellent beam quality

  • High reliability, high sealing

  • High power stability

  • Continuously adjustable power, fast switching response

  • Maintenance-free operation

  • High electro-optical conversion efficiency

  • Anti-high anti-reflection performanc

  • High modulation frequency, editable waveform

laser source.jpg

Welding gun

Ruida/Super Weiye/Qilin

welding gun.jpg

Water chiller

S&A  RMFL-1500/2000/3000

Water chiller.jpg

Wire feeder

Single wire feeder/ Double wire feeder

Wire feeder.jpg


This machine is for welding stainless steel, iron sheet, aluminum, copper, alloy, steel, etc. Widely used in the kitchen and bathroom industry, household electrical appliances industry, advertising industry, mold industry, doors and Windows industry, crafts industry, home products industry, furniture industry, lighting industry, auto parts industry, etc.


Samples Show:




Auto parts industry                 Door and window industry            Advertising industry                  Furniture industry



Related Products

This machine is for welding stainless steel, iron sheet, aluminum, copper, alloy, steel. Welding without smoke, no glare,ultra-low noise!
Widely applied in cabinets, kitchens, stair elevators, shelves, ovens, stainless steel doors and windows, guardrials,districbution boxes, stainless steel household industries.
